Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard
Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard
Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard
Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard

Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard

Brand: ASUS
SKU: ROG-X870-A-GAMING-WIFI
Availability: In stock

Key Features

Model: ROG STRIX X870-A GAMING WIFI

Supported CPU: AMD Socket AM5 for Ryzen 9000/8000 & 7000 Series Processors

Supported Memory: 4 x DIMM slots, max. 256GB, DDR5, Up to 8000+MT/s(OC) with Ryzen

Graphics Output: 1 x DisplayPort, 1 x HDMI port, 2x USB4 (up to 40Gbps transfer rate)

Features: 1 x Intel 2.5Gb Ethernet, Wi-Fi 7, Bluetooth V5.4

Ask an expert
Tk 65,000
Tk 72,490
Tk 65,000
Subtotal: Tk 65,000
Description

Specification

Basic Information

Supported CPU AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
Chipset AMD X870
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Form Factor ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Audio OG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel"
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover

Expansion Slots

PCI AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
1 x PCIe 5.0 x16 slot (supports x16 mode)
AMD Ryzen™ 8000 Series Desktop Processors*
1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**
AMD X870 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
* Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).
** Specifications vary by CPU types.
M.2 Socket Supports 4 x M.2 slots and 2 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode)**
AMD Ryzen™ 8000 Series Desktop Processors**
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode)
M.2_2 slot (Key M), type 2280/22110 (Not supports)****
AMD X870 Chipset
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)***
M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
2 x SATA 6Gb/s ports
* AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen™ 9000 series CPU.
** M.2_2 shares bandwidth with PCIEX16(G5). When M.2_2 is occupied with SSD device, PCIEX16(G5) will run x8 only.
*** M.2_3 shares bandwidth with PCIEX16(G4). When M.2_3 is occupied with SSD device, PCIEX16(G4) will be disabled.
**** M.2_2 will be disabled when using AMD Ryzen™ 8000 Series Desktop Processors.



Memory

Type DDR5
Slots 4 x DIMM
Supported Memory Supports up to 8000+MT/s(OC) with Ryzen
9000 & 8000 & 7000 Series Processors, ECC and Non-ECC, Un-buffered Memory
Dual channel memory architecture
Supports AMD Extended Profiles for
Overclocking (EXPO)
ASUS Enhanced Memory Profile (AEMP)
Maximum Memory 192GB



Graphics

Graphics 1 x DisplayPort
1 x HDMI port
2 x USB4 (40Gbps) ports support USB
Type-C display outputs
* Please refer to AMD CPU specifications.
Supports max. 8K@30Hz as specified in
DisplayPort 1.4.
Supports 4K@60Hz as specified in HDMI
2.1.
Supports max. 4K@60Hz as specified in
DisplayPort 1.4a
VGA resolution support depends on
processors' or graphic cards' resolution.



Connector & Ports

HDMI 1x HDMI
Display Port (s) 1x DisplayPort
USB (s) Rear USB (Total 12 ports)
2 x USB4® (40Gbps) ports(2 x USB Type-C with DP Alt mode)*
6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C with up to 30W PD Fast-charge)**
4 x USB 5Gbps ports (4 x Type-A)
Front USB (Total 9 ports)
1 x USB 20Gbps connector (supports USB Type-C)
2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
* USB Type-C power delivery output: max. 5V/3A
** USB Type-C power delivery output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A
LAN Port (s) 1 x Intel 2.5Gb Ethernet
ASUS LANGuard
Wireless Communication module Wi-Fi 7*
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
Bluetooth® v5.4***
*Wi-Fi features may vary depending on the operating system
For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
For Windows 10, please note that no driver is available , please refer to the Wi-Fi chipset vendor's website for details.
Supported Storage upports 4 x M.2 slots and 2 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode)**
AMD Ryzen™ 8000 Series Desktop Processors**
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode)
M.2_2 slot (Key M), type 2280/22110 (Not supports)****
AMD X870 Chipset
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)***
M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
2 x SATA 6Gb/s ports
* AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen™ 9000 series CPU.
** M.2_2 shares bandwidth with PCIEX16(G5). When M.2_2 is occupied with SSD device, PCIEX16(G5) will run x8 only.
*** M.2_3 shares bandwidth with PCIEX16(G4). When M.2_3 is occupied with SSD device, PCIEX16(G4) will be disabled.
**** M.2_2 will be disabled when using AMD Ryzen™ 8000 Series Desktop Processors.
RAID AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen™ 9000 series CPU
Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel"
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
* The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
Internal I/O Ports Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
5 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connectors
Storage Related
4 x M.2 slots (Key M)
2 x SATA 6Gb/s ports
USB
1 x USB 20Gbps connector (supports USB Type-C®)
2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Alteration PCIe mode switch
1 x Chassis Intrusion header
1 x CPU Over voltage jumper
1 x Front Panel Audio header (F_AUDIO)
1 x Start button
1 x 10-1 pin System Panel header
1 x Thermal Sensor header

Back Panel I/O Ports
2 x USB4® (40Gbps) ports (2 x USB Type-C® with DP Alt mode)
6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C® with up to 30W PD Fast-charge)**
4 x USB 5Gbps ports (4 x Type-A)
1 x DisplayPort
1 x HDMI™ port
1 x Wi-Fi module
1 x Intel 2.5Gb Ethernet
2 x Audio jacks 
1 x Optical S/PDIF out port
1 x BIOS FlashBack button 
1 x Clear CMOS button 



Others

Special Features Extreme Engine Digi+
- 5K Black metallic capacitors
ASUS Q-Design
- M.2 Q-Latch
- M.2 Q-Release
- M.2 Q-Slide
- PCIe Slot Q-Release Slim (with PCIe SafeSlot)
- Q-Antenna
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
- M.2 heatsink
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- Clear CMOS button
- ProCool II
- Pre-mounted I/O shield
- SafeSlot
- SafeDIMM
Aura Sync
- Addressable Gen 2 headers
Bundled Software ROG Exclusive Software
- ROG CPU-Z
- Dolby Atmos
ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (60 days free trial)
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- GameFirst
- HWiNFO
- Power Saving
ASUS Driver Hub
ASUS GlideX
USB Wattage Watcher
TurboV Core
Adobe Creative Cloud (Free Trial)
Norton 360 for Gamers (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey
Dynamic OC Switcher
FlexKey



Warranty

Warranty 3 years

Description

Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard

The Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard is a premium, high-performance motherboard engineered for gamers, creators, and professionals who demand cutting-edge power, stability, and design. Built on the AMD X870 chipset and featuring the AM5 socket, it supports the latest AMD Ryzen 9000, 8000, and 7000 Series Desktop Processors, ensuring future-ready compatibility and unmatched performance for next-generation computing.

This Asus ROG STRIX X870-A GAMING WIFI motherboard supports up to 192GB of DDR5 memory across four DIMM slots, delivering blazing-fast speeds and efficient multitasking for gaming, rendering, and content creation. Equipped with AMD EXPO and ASUS AEMP memory tuning profiles, users can push their RAM performance beyond 8000MT/s (OC) for smooth, lag-free operation even under heavy workloads.

Storage expansion is extensive, with four M.2 slots and two SATA 6Gb/s ports, enabling high-speed NVMe SSDs and large-capacity drives for faster game loading, application execution, and data storage. The PCIe 5.0 x16 SafeSlot supports the latest graphics cards with enhanced durability and stability, making it perfect for high-end GPUs and AI workloads.

Connectivity is truly next-gen. With dual USB4 Type-C ports, Wi-Fi 7, Bluetooth 5.4, and 2.5Gb Ethernet, the Asus ROG STRIX X870-A ensures lightning-fast data transfer, stable networking, and low-latency gaming. Multiple rear and front-panel USB ports, including USB 20Gbps Type-C, provide ample options for peripherals and external storage.

Power delivery is handled by a robust 16+2+2 power stage design, ensuring clean, stable voltage to the CPU and GPU for reliable overclocking and consistent performance. Enhanced cooling is achieved through massive VRM heatsinks, high-conductivity thermal pads, and optimized airflow channels, keeping temperatures under control during intense gaming or heavy multitasking.

DIY enthusiasts will appreciate Asus’s signature Q-Design features such as M.2 Q-Latch, PCIe Slot Q-Release Slim, and a pre-mounted I/O shield, simplifying installation and upgrades. Additional protection and durability come from ASUS 5X Protection III, ensuring long-lasting component life and system stability.

The Asus ROG STRIX X870-A GAMING WIFI also excels in aesthetics and audio. Its sleek, futuristic design features Aura Sync RGB lighting, allowing full customization and synchronization across compatible ROG peripherals. For sound, the ROG SupremeFX ALC4080 codec delivers crystal-clear, immersive audio with 32-bit/384kHz playback, premium capacitors, and superior signal isolation — perfect for gaming and content creation.

With support for Fan Xpert 4, Armoury Crate, and AI-based system optimization, this motherboard provides full control over performance tuning, cooling profiles, and lighting effects, all from a single, intuitive interface.

The Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard combines high-end performance, premium design, and intelligent features, making it the ultimate foundation for building a powerful, future-proof gaming or creative workstation.

Price in Bangladesh: 65,000৳
Buy the Asus ROG STRIX X870-A GAMING WIFI AMD AM5 ATX Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This motherboard comes with a 3-year warranty.
