Brand: ASUS
SKU: ROG-B850-I-GAMING-WIFI
Availability: In stock

Key Features

Model: ROG STRIX B850-I GAMING WIFI

Supported CPU: AMD Socket AM5 for AMD Ryzen 9000, 8000 & 7000 Series

Supported RAM: 2 x DDR5, up to 128GB, 8400+ MT/s (OC)

Graphics Output: 1x HDMI, 1x USB Type-C

Features: Intel 2.5Gb Ethernet, Wi-Fi 7, Bluetooth 5.4

Ask an expert
Tk 49,000
Tk 52,950
Tk 49,000
Subtotal: Tk 49,000
Description

Specification

Basic Information

Supported CPU AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
Chipset AMD B850
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Form Factor Mini-ITX Form Factor
6.7 inch x 6.7 inch (17 cm x 17 cm)
Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

Expansion Slots

PCI AMD Ryzen 9000 & 7000 Series Desktop Processors
1 x PCIe 5.0 x16 slot with Q-Release Slim
AMD Ryzen 8000 Series Desktop Processors
1 x PCIe 4.0 x16 slot with Q-Rlease Slim
M.2 Socket 2 x M.2



Memory

Type DDR5
Slots 2 x DIMM
Supported Memory 2 x DIMM slots, max. 128GB, DDR5
Supports up to 8400+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors
ECC and Non-ECC, Un-buffered DIMM
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
ASUS Enhanced Memory Profile (AEMP)
Maximum Memory 128GB



Graphics

Graphics 1 x HDMI™ port***
1 x USB 10Gbps ports support USB Type-C® display outputs****
* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
*** Supports 4K@60Hz as specified in HDMI 2.1.
****Supports max. 4K@60Hz as specified in DisplayPort 1.4a
***** VGA resolution support depends on processors' or graphic cards' resolution.



Connector & Ports

HDMI 1x HDMI 2.1
USB (s) Rear USB (Total 8 ports)
1 x USB 20Gbps port(s) (1 x USB Type-C®)
5 x USB 10Gbps port(s) (4 x Type-A + 1 x USB Type-C®)
2 x USB 2.0 port(s) (2 x Type-A)

Front USB (Total 5 ports)
1 x USB 10Gbps
1 x USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports
1 x USB 2.0 header(s) support(s) 2 additional USB 2.0 ports
USB Type-C power delivery output: max. 5V/3A
LAN Port (s) 1 x Intel 2.5Gb Ethernet
ASUS LANGuard
Wireless Communication module Wi-Fi 7*
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
Bluetooth® v5.4***
Supported Storage Total supports 2 x M.2 slots and 2 x SATA 6Gb/s ports

AMD Ryzen™ 7000 & 9000 Series Desktop Processors
M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 5.0x4 mode)
M.2_2 (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
AMD Ryzen 8000 Series Desktop Processors
M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 4.0x4 mode)
M.2_2 (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)*
* Specifications vary by CPU types.
Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
Internal I/O Ports Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin Extra Flow Fan header
1 x 4-pin AIO Pump header
1 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
1 x 8-pin +12V CPU Power connector
Storage Related
2 x M.2 slots (Key M)
2 x SATA 6Gb/s ports
USB
1 x USB 10Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
1 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
2 x Addressable Gen 2 headers
1 x CPU Over voltage jumper
1 x Front Panel Audio header (F_AUDIO)
1 x 10-1 pin Front System Panel header
1 x Thermal Sensor header

Back Panel I/O Ports
1 x USB 20Gbps port(s)
5 x USB 10Gbps port(s) (4 x Type-A + 1 x USB Type-C® with DP Alt mode)
2 x USB 2.0 port(s) (2 x Type-A)
1 x HDMI™ port
1 x Wi-Fi module
1 x Intel® 2.5Gb Ethernet port
3 x Audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™ button
1 x Clear CMOS button
1 x FlexKey button



Others

Special Features Extreme Engine Digi+
- 5K Black metallic capacitors
ASUS Q-Design
- M.2 Q-Latch
- M.2 Q-Slide
- PCIe Slot Q-Release Slim (with PCIe SafeSlot)
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
- M.2 heatsink
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- Clear CMOS button
- ProCool
- Pre-mounted I/O shield
- SafeSlot
- SafeDIMM
Aura Sync
- Addressable Gen 2 headers
Bundled Software ROG Exclusive Software
- ROG CPU-Z
- Dolby Atmos
ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (60 days free trial)
- Aura Creator
- Aura Sync
- Fan Xpert 4
- GameFirst
- HWiNFO
- Power Saving
ASUS DriverHub
ASUS GlideX
TurboV Core
Adobe Creative Cloud (Free Trial)
Norton 360 for Gamers (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey



Warranty

Warranty 3 years

Description

Asus ROG STRIX B850-I GAMING WIFI AM5 Mini-ITX Motherboard

The Asus ROG STRIX B850-I GAMING WIFI AM5 Mini-ITX Motherboard is a compact yet powerful gaming motherboard designed to deliver exceptional performance and cutting-edge features in a small form factor. Built on the AMD B850 chipset with the AM5 socket, it supports the latest AMD Ryzen 9000, 8000, and 7000 Series Desktop Processors, making it an ideal choice for gamers and creators looking to build a high-performance mini gaming rig or workstation.

Despite its compact size, this Asus ROG STRIX Mini-ITX Motherboard offers incredible power and flexibility. It supports up to 128GB of DDR5 memory with overclocking speeds reaching 8000+ MT/s (OC), ensuring superior performance for multitasking, gaming, and content creation. With dual-channel architecture and support for AMD EXPO and ASUS AEMP profiles, users can easily fine-tune memory performance for maximum speed and stability.

Storage options are lightning-fast, featuring two PCIe 5.0 M.2 slots for next-generation NVMe SSDs and two SATA 6Gb/s ports, allowing ample room for both high-speed and high-capacity drives. Expansion is made simple with a full-length PCIe 5.0 x16 slot, providing compatibility with the latest GPUs while maintaining excellent thermal efficiency within the compact Mini-ITX form factor.

Connectivity is future-ready, including Wi-Fi 7 for ultra-low latency wireless networking, Bluetooth 5.3 for smooth peripheral connections, and multiple USB Type-C and Type-A ports for high-speed data transfers. The ROG SupremeFX ALC4080 audio codec ensures immersive, studio-quality sound with 24-bit/192kHz playback, audio shielding, and premium capacitors for clear and powerful audio output.

Built with reliability in mind, the Asus ROG STRIX B850-I GAMING WIFI features a 10+2+1 power stage design for stable power delivery, reinforced by high-quality chokes, capacitors, and DIGI+ VRM technology. Cooling is handled efficiently with large VRM heatsinks, high-conductivity thermal pads, and AI-enhanced thermal management through Fan Xpert 4 to keep temperatures optimized under load.

DIY-friendly features like M.2 Q-Latch and PCIe Slot Q-Release Slim make installation quick and convenient, while Q-LED indicators simplify troubleshooting. Aesthetically, the motherboard showcases Aura Sync RGB lighting with customizable effects, allowing full synchronization with compatible ROG peripherals and components for a unified and stylish setup.

With its perfect combination of power, efficiency, and style, the Asus ROG STRIX B850-I GAMING WIFI AM5 Mini-ITX Motherboard stands out as the ultimate choice for small-form-factor gaming builds and professional compact systems.

Price in Bangladesh: 49,000৳
Buy the Asus ROG STRIX B850-I GAMING WIFI AM5 Mini-ITX Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This motherboard comes with a 3-year warranty.
