Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard
Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard
Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard
Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard

Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard

Brand: ASUS
SKU: ROG-X870E-HERO
Availability: In stock

Key Features

Model: ROG CROSSHAIR X870E HERO

Supported CPU: Ryzen 9000, 8000/ 7000 Series Processors for Socket AM5

Supported RAM: 4 x DDR5, up to 256GB, 8200+(OC)

Graphics Output: 1x HDMI, 2x USB4

Features: 1 x 2.5Gb, 1x5Gb LAN, Wi-Fi 7, Bluetooth 5.4

Ask an expert
Tk 104,300
Tk 113,380
Tk 104,300
Subtotal: Tk 104,300
Description

Specification

Basic Information

Supported CPU AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
Chipset AMD X870E
BIOS 256Mb Flash ROM, UEFI AMI BIOS
Form Factor ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel
Audio Features
- SupremeFX Shielding Technology
- ESS® ES9219 QUAD DAC
- Gold-plated audio jacks
- Rear optical S/PDIF out port
- Premium audio capacitors
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.

Expansion Slots

PCI AMD Ryzen 9000 & 7000 Series Desktop Processors*
2 x PCIe 5.0 x16 slots with Q-Release Slim (supports x16 or x8/x8** or x8/x4/x4 modes***)
** When you use both PCIEX16_1 and PCIEX16_2, PCIEX16_1 and PCIEX16_2 will run x8.
*** When M.2_3 are enabled, PCIEX16_1 will run x8, and PCIEX16_2 will run x4.
**** When M.2_2 and M.2_3 are enabled simultaneously, PCIEX16_2 will be disabled.
AMD Ryzen 8700 & 8600 & 8400 Series Desktop Processors*
2 x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16_1 & total bandwidth for x8, PCIEx16_2 will be disabled)
AMD Ryzen 8500 & 8300 Series Desktop Processors*
2 x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16_1 & total bandwidth for x4, PCIEx16_2 will be disabled)
M.2 Socket Supports 5 x M.2 slots



Memory

Type DDR5
Slots 4 x DIMM
Supported Memory Supports up to
8200+MT/s(OC) with Ryzen™ 9000 Series Processors,
8600+MT/s(OC) with Ryzen™ 8000 Series Processors,
8000+MT/s(OC) with Ryzen™ 7000 Series Processors,
ECC and Non-ECC, Un-buffered Memory*
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
NitroPath DRAM Technology
ASUS Enhanced Memory Profile (AEMP)
Maximum Memory 256GB



Graphics

Graphics 1 x HDMI port*
2 x USB4 (40Gbps) ports support USB Type-C



Connector & Ports

HDMI 1x HDMI
USB (s) Rear USB (Total 10 ports)
2 x USB4® (40Gbps) ports (2 x USB Type-C®)
8 x USB 10Gbps ports (6 x Type-A + 2 x USB Type-C®)
Front USB (Total 10 ports)
1 x USB 20Gbps (supports USB Type-C® with up to 60W PD/QC4+)*
1 x USB 20Gbps connector (supports USB Type-C)
2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
USB Type-C power delivery output: max. 5V/3A
*USB Type-C power delivery output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A
LAN Port (s) 1 x Intel 2.5Gb Ethernet
1 x Realtek 5Gb Ethernet
Wireless Communication module Wi-Fi 7*
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 320MHz bandwidth, up to 6.5Gbps transfer rate.
Bluetooth v5.4***
Supported Storage Supports 5 x M.2 slots and 1 x SlimSAS connector and 4 x SATA 6Gb/s ports*
AMD Ryzen 9000 & 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
AMD Ryzen 8000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (Not supports)
M.2_3 slot (Key M), type 2242/2260/2280 (Not supports)
AMD X870E Chipset
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
SlimSAS slot supports PCIe 4.0 x4 mode.
4 x SATA 6Gb/s ports
** When M.2_2 and M.2_3 are enabled simultaneously, PCIEX16_2 will be disabled.
***When M.2_3 are enabled, PCIEX16_1 will run x8, and PCIEX16_2 will run x4, M.2_2 will be disabled.
AMD RAIDXpert2 Technology
Ryzen 9000 Series Processors: RAID 0/1/5/10
Ryzen 8000 Series Processors: RAID 0/1
Ryzen 7000 Series Processors: RAID 0/1/10
RAID Ryzen 9000 Series Processors: RAID 0/1/5/10
Ryzen 8000 Series Processors: RAID 0/1
Ryzen 7000 Series Processors: RAID 0/1/10
Audio 2 x Gold-plated audio jacks
Internal I/O Ports Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
1 x W_PUMP+ header
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connector
1 x 8-pin PCIe Power connector
Storage Related
5 x M.2 slots (Key M)
1 x SlimSAS connector
4 x SATA 6Gb/s ports
USB
2 x USB 20Gbps connectors (support USB Type-C® )
2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen2 headers
1 x Alteration PCIe mode switch
1 x FlexKey button
1 x Front Panel Audio header (F_AUDIO)
1 x ReTry button
1 x Start button
1 x 10-1 pin System Panel header
1 x Thermal Sensor header
1 x LN2 Mode jumper

Back Panel I/O Ports
2 x USB4® (40Gbps) ports (2 x USB Type-C®)
8 x USB 10Gbps ports (6 x Type-A + 2 x USB Type-C®)
1 x HDMI™ port
1 x Wi-Fi module
1 x Intel® 2.5Gb Ethernet port
1 x Realtek 5Gb Ethernet port
2 x Gold-plated audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™ button
1 x Clear CMOS button



Others

Special Features Extreme OC Kit
- FlexKey button
- LN2 Mode
- ReTry button
- Start button
Extreme Engine Digi+
- 10K Black metallic capacitors
- MicroFine alloy choke
ASUS Q-Design
- M.2 Q-Latch
- M.2 Q-Release
- M.2 Q-Slide
- Q-Release Slim (with PCIe SafeSlot)
- Q-Antenna
- Q-Code
- Q-Connector
- Q-Dashboard
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
- M.2 heatsink
- VRM heatsink design
- Metal backplate
ASUS EZ DIY
- Backplate
- BIOS FlashBack™ button
- Clear CMOS button
- ProCool II
- Pre-mounted I/O shield
- SafeSlot
- SafeDIMM
Aura Sync
- Addressable Gen2 header(s)
Front Panel USB 20Gbps with Quick Charge 4+ Support
- Support: up to 60W fast charging and USB Wattage Watcher*
- Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A
- Compatible with PD3.0 and PPS
* To support 60W, please install the power cable to the 8-pin PCIe power connector or else only 27W will be supported.
Bundled Software ROG Exclusive Software
- ROG CPU-Z
- Dolby Atmos
- Internet Security (1-year full version)
- Polymo Lighting II
ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (1 year full version)
- Aura Creator
- Aura Sync
-Fan Xpert 4 (with AI Cooling II)
- GameFirst
- HWiNFO
- Power Saving
ASUS DriverHub
ASUS GlideX
USB Wattage Watcher
TurboV Core
WinRAR (40 Days Free Trial)
Adobe Creative Cloud (Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey
FlexKey



Warranty

Warranty 3 years

Description

Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard

The Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard stands as the pinnacle of innovation and performance within the ASUS ROG lineup. Engineered for gamers, creators, and professionals who demand the absolute best, this flagship motherboard combines cutting-edge hardware, AI-driven optimization, and uncompromising design to deliver elite computing power for next-generation workloads and gaming experiences.

Powered by the AMD X870E chipset and AM5 socket, the ROG CROSSHAIR X870E HERO supports the latest AMD Ryzen 9000, 8000, and 7000 Series Desktop Processors, unlocking the full potential of AMD’s most advanced CPU architectures. With support for up to 192GB of DDR5 RAM, it delivers blazing-fast data throughput and superior multitasking performance, enhanced further by AMD EXPO and ASUS AEMP II memory tuning profiles for effortless overclocking and stability.

The motherboard offers unparalleled expandability, featuring five M.2 slots, one SlimSAS connector, and four SATA 6Gb/s ports, accommodating both PCIe Gen 5 and Gen 4 SSDs for ultimate storage flexibility. This makes it ideal for professionals handling 4K/8K video editing, 3D rendering, and large data-intensive projects.

Connectivity is future-proof and versatile. The dual USB4 Type-C ports deliver up to 40Gbps transfer speeds, while Wi-Fi 7 ensures lightning-fast, low-latency wireless networking. For wired connections, the integrated 2.5Gb Ethernet guarantees stable and high-speed data transmission. Expansion options include multiple PCIe 5.0 x16 slots, supporting the latest GPUs and add-on cards for extreme performance.

The Asus ROG CROSSHAIR X870E HERO is built with a robust 18+2+2 power stage design, ensuring clean and reliable power delivery to handle even the most demanding CPUs under sustained load. Combined with high-quality alloy chokes, ProCool II connectors, and military-grade capacitors, it provides industry-leading efficiency and durability.

Thermal performance is exceptional, thanks to AI Cooling II, which intelligently monitors temperatures and adjusts fan speeds for optimal balance between acoustics and cooling efficiency. The motherboard’s large VRM heatsinks, dedicated M.2 heatsinks, and integrated thermal pads keep your system cool during overclocking and intensive gaming sessions.

For ease of use, ASUS includes several DIY-friendly features, such as PCIe Slot Q-Release Slim, M.2 Q-Latch, Q-LED indicators, and a pre-mounted I/O shield, simplifying installation and maintenance.

The audio experience is nothing short of premium with the ROG SupremeFX 7.1 Surround Sound System powered by a high-fidelity codec, delivering crystal-clear, immersive sound for both gaming and content creation.

With Aura Sync RGB lighting, users can customize their rig’s aesthetics with millions of colors and synchronized effects across compatible devices. Exclusive software tools like Armoury Crate, AI Suite 3, ROG TurboV Core, and Fan Xpert 4 provide full control over system performance, cooling, and customization.

Blending world-class engineering, powerful AI-assisted features, and cutting-edge connectivity, the Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard sets a new benchmark for high-end gaming and professional performance.

Price in Bangladesh: 104,300৳
Buy the Asus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This motherboard comes with a 3-year warranty.
