Asus PRIME X870-P-CSM AM5 ATX Motherboard
Asus PRIME X870-P-CSM AM5 ATX Motherboard

Asus PRIME X870-P-CSM AM5 ATX Motherboard

Brand: ASUS
SKU: PRIME-X870-P-CSM
Availability: In stock

Key Features

Model: PRIME X870-P-CSM

Supported CPU: Ryzen 9000/8000 & 7000 Series Processors for AM5 Socket

Supported Memory: 4 x DIMM, Max. 192GB, DDR5 Up to 8000+(OC)

Graphics Output: 1 x HDMI port, 2x USB 4 (Type-C up to 40Gbps Data Transfer)

Features: Realtek 2.5Gb Ethernet, Realtek 7.1 Surround Sound

Ask an expert
Tk 41,700
Tk 45,030
Tk 41,700
Subtotal: Tk 41,700
Description

Specification

Basic Information

Supported CPU AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
Chipset AMD X870 Chipset
BIOS 256 Mb Flash ROM, UEFI AMI BIOSc
Form Factor ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Expansion Slots

PCI AMD Ryzen 7000 Series Desktop Processors
1 x PCIe 4.0 x16 slot (supports x16 mode)
AMD X670 Chipset
2 x PCIe 4.0 x16 slots (support x4 mode)
1 x PCIe 3.0 x1 slot
M.2 Socket AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
1 x PCIe 5.0 x16 slot (supports x16 mode)
AMD Ryzen™ 8000 Series Desktop Processors
1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**
AMD X870 Chipset
3 x PCIe 4.0 x16 slots (support x1 mode)***
** Specifications vary by CPU types.
*** PCIEX16(G4)_1 shares bandwidth with M.2_2. PCIEX16(G4)_1 will be disabled when M.2_2 runs.
*** PCIEX16(G4)_2 and PCIEX16(G4)_3 share bandwidth with M.2_3. PCIEX16(G4)_2 and PCIEX16(G4)_3 will be disabled when M.2_3 runs.



Memory

Type DDR5
Slots 4 x DIMM
Supported Memory Supports up to 8000+MT/s(OC) with Ryzen 9000 & 8000 & 7000 Series Processors
ECC and Non-ECC, Un-buffered DIMM*
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO)
ASUS Enhanced Memory Profile (AEMP)
Maximum Memory 192GBB



Graphics

Graphics 1 x HDMI™ port**
2 x USB4® (40Gbps) ports support USB Type-C® display outputs***
* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
** Supports 4K@60Hz as specified in HDMI 2.1.
*** Supports max. 4K@60Hz as specified in DisplayPort 1.4a.
**** VGA resolution support depends on processors' or graphic cards' resolution.



Connector & Ports

HDMI 1x HDMI 2.1
USB (s) 2 x USB4 (40Gbps) ports support USB Type-C display outputs**

Rear USB (Total 10 ports)
2 x USB4 (40Gbps) ports (2 x USB Type-C)
1 x USB 10Gbps port (1 x Type-A)
3 x USB 5Gbps ports (3 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 7 ports)
1 x USB 10Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
* USB Type-C power delivery output: max. 5V/3A
LAN Port (s) 1 x Realtek 2.5Gb Ethernet
Supported Storage Supports 4 x M.2 slots and 2 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
AMD Ryzen™ 8000 Series Desktop Processors
M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
AMD X870 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)**
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)***
M.2_4 slot (Key M), type 2280 (supports PCIe 3.0 x2 mode)****
2 x SATA 6Gb/s ports****
* AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen™ 9000 series CPU.
** PCIEX16(G4)_1 shares bandwidth with M.2_2. PCIEX16(G4)_1 will be disabled when M.2_2 runs.
*** PCIEX16(G4)_2 and PCIEX16(G4)_3 share bandwidth with M.2_3. PCIEX16(G4)_2 and PCIEX16(G4)_3 will be disabled when M.2_3 runs.
**** M.2_4 shares bandwidth with SATA6G_1 and SATA6G_2. M.2_4 will be disabled when SATA6G_1 or SATA6G_2 runs.
RAID * AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen™ 9000 series CPU.
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz
Internal I/O Ports Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connectors
Storage Related
4 x M.2 slots (Key M)
2 x SATA 6Gb/s ports
USB
1 x USB 10Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x S/PDIF Out header
1 x SPI TPM header (14-1 pin)
1 x 10-1 pin System Panel header
TPM (Trusted Platform Module ) 1 x SPI TPM header (14-1 pin)



Others

Special Features ASUS 5X PROTECTION III
- DIGI+ VRM (- Digital power design with DrMOS)
- LANGuard
- Overvoltage protection
- SafeSlot
- Stainless-steel back I/O
ASUS Q-Design
- M.2 Q-Latch
- PCIe Slot Q-Release
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED Core
- Q-Slot
ASUS Thermal Solution
- Flexible M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- ProCool
- Pre-mounted I/O shield
- SafeSlot
Aura Sync
- Addressable Gen 2 headers
Bundled Software ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
ASUS DriverHub
ASUS GlideX
TurboV Core
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey



Warranty

Warranty 3 years

Description

Asus PRIME X870-P-CSM AM5 ATX Motherboard

The Asus PRIME X870-P-CSM AM5 ATX Motherboard is a high-performance and future-ready platform built for professionals, enthusiasts, and everyday users who value stability, expandability, and efficiency. Powered by the advanced AMD X870 chipset and featuring the AM5 socket, it supports the latest AMD Ryzen 7000, 8000, and 9000 Series Desktop Processors, delivering exceptional performance across productivity, gaming, and creative workloads.

Engineered for high-speed computing, the motherboard supports up to 192GB of DDR5 memory across four DIMM slots, achieving speeds beyond 8000+ MT/s (OC) for rapid multitasking and seamless application handling. With PCIe 5.0 x16 SafeSlots, it is fully prepared for next-generation graphics cards, ensuring top-tier performance for demanding 3D rendering, gaming, and professional workloads.

Storage flexibility is another highlight of the Asus PRIME X870-P-CSM, featuring four M.2 slots (PCIe 5.0 & 4.0 compatible) and two SATA 6Gb/s ports, allowing users to combine high-speed NVMe drives with large-capacity HDDs for optimal performance and storage balance.

Connectivity is cutting-edge, featuring dual USB4 (40Gbps) Type-C ports, multiple USB 10Gbps and 5Gbps ports, and high-speed networking for smooth data transfer and reliable communication. The motherboard is also built with 14+2+1 power stages, premium capacitors, and alloy chokes, ensuring consistent and efficient power delivery to all key components — perfect for heavy multitasking and high-performance builds.

Thermal performance is ensured by optimized heatsinks, VRM cooling modules, and intelligent Fan Xpert controls, maintaining system stability even during intense workloads. Whether for gaming, content creation, or data-heavy computing, the Asus PRIME X870-P-CSM stays cool, quiet, and reliable.

For builders, the pre-mounted I/O shield, Q-Design features (including M.2 Q-Latch and PCIe Slot Q-Release), and intuitive UEFI BIOS make setup and customization fast and easy — even for first-time builders. The motherboard’s robust construction and ASUS 5X Protection III ensure long-term durability, guarding against electrical damage, power surges, and component wear.

Complementing its power and practicality, Aura Sync RGB lighting with Gen 2 ARGB headers adds customizable aesthetics, allowing users to create visually stunning builds.

The Asus PRIME X870-P-CSM AM5 ATX Motherboard perfectly combines power, performance, and dependability, making it a top-tier choice for professionals, creators, and users looking to build a future-proof and versatile PC.

Price in Bangladesh: 41,700৳
Buy the Asus PRIME X870-P-CSM AM5 ATX Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This motherboard comes with a 3-year warranty.
