MSI PRO B850M-P WIFI AM5 mATX Motherboard

MSI PRO B850M-P WIFI AM5 mATX Motherboard

Brand: MSI (AMD)
SKU: PRO B850M-P WIFI
Availability: In stock

Key Features

Graphics Output: 1x HDMI, 1x DisplayPort
Supported RAM: 4x DDR5 UDIMM, Up to 8200 (OC) Mhz
Features: 3x M.2 Slot, Realtek 8126VB 5G LAN, Wi-Fi 7, Bluetooth 5.4
Supported CPU: AMD Ryzen 9000/8000/7000 Series for Socket AM5

Ask an expert
Tk 23,200
Tk 23,500
Tk 23,200
Subtotal: Tk 23,200
Description

Specification

Basic Information

Supported CPU Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
Chipset AMD B850
BIOS Flash BIOS Button
Form Factor mATX
243.84mmx243.84mm
Audio Realtek ALC897
7.1-Channel High Definition Audio

Expansion Slots

PCI 4x PCI-E x16 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)

PCI_E1 slot
Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors)
Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors)
Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processor)
M.2 Socket 3x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280 devices
4x SATA 6G

M2_1 slot
Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors)
Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors)

M2_2 slot
Supports up to PCIe 4.0 x4
Supports up to PCIe 4.0 x2 (For Ryzen 8500/ 8300 Series processors)



Memory

Type DDR5
Slots 4x UDIMM
Supported Memory Memory Support 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s
Ryzen 9000 Series Processors max. overclocking frequency:
1DPC 1R Max speed up to 8200+ MT/s
1DPC 2R Max speed up to 6400+ MT/s
2DPC 1R Max speed up to 6400+ MT/s
2DPC 2R Max speed up to 6000+ MT/s

Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPOTM
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only

CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility.
The DIMM slots on this motherboard only have single-sided latches.
Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www.msi.com/support/.
Maximum Memory 256GB

Graphics

Graphics 1x HDMI
Support HDMITM 2.1, maximum resolution of 4K 60Hz

1x DisplayPort
Support DisplayPort 1.4, maximum resolution of 4K 60Hz

Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.



Connector & Ports

HDMI 1x HDMI
Support HDMITM 2.1, maximum resolution of 4K 60Hz
Display Port (s) 1x DisplayPort
Support DisplayPort 1.4, maximum resolution of 4K 60Hz
USB (s) 4x USB 2.0 (Rear)
4x USB 2.0 (Front)
2x USB 5Gbps Type A (Rear)
4x USB 5Gbps Type A (Front)
1x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Rear)
1x USB 10Gbps Type C (Front)
LAN Port (s) Realtek 8126VB 5G LAN
Wireless Communication module Wi-Fi 7
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (160MHz) up to 2.9Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be

Supports Bluetooth® 5.4, MLO, 4KQAM

6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2.
The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
Supported Storage 3x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280 devices
4x SATA 6G

M2_1 slot
Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors)

M2_2 slot
Supports up to PCIe 4.0 x4
Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors)
RAID Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1, and RAID 5 for M.2 NVMe storage devices
Audio 1x Front Audio (JAUD)
Internal I/O Ports 1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
3x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x Tuning Controller connector(JDASH)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports
1x USB 10Gbps Type C ports
TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0)



Others

Special Features 4x EZ Debug LED
1x EZ Memory Detection LED
Bundled Software Support for Windows 11 64-bit

Warranty

Warranty 3 years

Description

MSI PRO B850M-P WIFI AM5 mATX Motherboard

The MSI PRO B850M-P WIFI is a next-generation micro-ATX motherboard designed for users seeking top-tier performance, modern connectivity, and efficient thermal management in a compact form factor. Built to support AMD Ryzen 9000, 8000, and 7000 Series desktop processors on the AM5 socket, it fully unleashes the power of DDR5 memory with speeds up to 8200+ MT/s (OC), ensuring unmatched responsiveness for gaming, productivity, and creative workloads. Its advanced 7+2+1 direct power phase system, combined with Core Boost and Memory Boost technologies, guarantees stable and efficient power delivery across all cores, even during intense multitasking or overclocking.

Constructed with a 6-layer PCB made of 2oz thickened copper and server-grade materials, the PRO B850M-P WIFI ensures superior durability, heat resistance, and signal integrity. The Frozr Guard thermal design includes extended heatsinks, 7W/mK MOSFET pads, and choke pads to maintain optimal cooling. The EZ M.2 Shield Frozr II and tool-less installation clips simplify building and maintenance, while the chipset heatsink ensures quiet, dust-free operation for long-term reliability.

Connectivity is a major strength, featuring built-in Wi-Fi 7 and Realtek 8126VB 5G LAN for ultra-fast, low-latency networking — perfect for gaming, streaming, and professional use. The MSI PRO B850M-P WIFI supports PCIe 5.0 graphics and Gen 5 x4 M.2 SSDs, delivering blazing-fast data transfer speeds and next-gen GPU support. With three M.2 slots, four SATA 6G ports, and RAID 0, 1, 5, and 10 configurations, it offers exceptional storage flexibility. Audio Boost technology powered by Realtek ALC897 ensures rich, studio-grade sound quality for gaming and entertainment.

The rear I/O includes USB 10Gbps Type-A and Type-C ports, HDMI 2.1, DisplayPort 1.4 (supporting 4K 60Hz), and dedicated Flash BIOS and Clear CMOS buttons. Internal headers support RGB and ARGB lighting, multiple cooling fans, TPM 2.0, and front panel USB connections — ideal for custom builds and upgrades. Fully compatible with Windows 11 64-bit, the MSI PRO B850M-P WIFI AM5 mATX Motherboard is the perfect foundation for compact, high-performance PC builds.

Buy MSI PRO B850M-P WIFI AM5 mATX Motherboard from Tech Buy BD
In Bangladesh, you can get the original MSI PRO B850M-P WIFI AM5 mATX Motherboard from Tech Buy BD. We have a large collection of the latest MSI motherboards available for your desktop PC. Order online or visit your nearest Tech Buy BD shop to get yours at the best price. The MSI PRO B850M-P WIFI AM5 mATX Motherboard comes with 3 years warranty.
