GIGABYTE H610M K DDR5 Micro ATX Motherboard

SKU: H610M K DDR5
Availability: In stock

Key Features

Graphics Output: 1x HDMI 2.1, 1 x DisplayPort
Supported RAM: 2x DDR5, Max 128GB 5333(OC)
Features: Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)

Tk 10,900
Tk 11,400
Tk 10,900
Subtotal: Tk 10,900

Specification

Basic Information

Supported CPU LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core, Pentium Gold and Celeron Processors
L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)
Chipset Intel H610 Express Chipset
BIOS 1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 23.0cm x 21.5cm
Audio Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Support for S/PDIF Out

Expansion Slots

PCI CPU:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
Chipset:
- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1

Memory

Type DDR5
Slots 2 x DIMM sockets
Supported Memory Support for 5600/5200/4800/4400 MT/s memory modules
13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:
4800/4400 MT/s memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor
Maximum Memory Supporting up to 128 GB (64 GB single DIMM capacity) of system memory



Graphics

Graphics Integrated Graphics Processor-Intel HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version and HDCP 2.3.
** Support native HDMI 2.1 TMDS compatible ports.


- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3


(Graphics specifications may vary depending on CPU support.)



Connector & Ports

HDMI 1 x HDMI port
Display Port (s) 1 x DisplayPort
USB (s) Chipset:
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
LAN Port (s) Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Supported Storage Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 3.0 x4/x2 SSD support)
- 2 x SATA 6Gb/s connectors
Internal I/O Ports Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x M.2 Socket 3 connector
2 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Clear CMOS jumper

Back Panel Connectors
1 x HDMI port
1 x DisplayPort
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

Others

Special Features iTE I/O Controller Chip
Bundled Software Norton Internet Security (OEM version)
LAN bandwidth management software

Warranty

Warranty 3 years

Description

GIGABYTE H610M K DDR5 Micro ATX Motherboard

The GIGABYTE H610M K DDR5 Micro ATX Motherboard is engineered to deliver next-generation performance and stability for modern PC builds. Designed with the LGA1700 socket, it supports the latest 14th, 13th, and 12th Generation Intel Core, Pentium Gold, and Celeron processors, making it an ideal choice for users who demand speed, efficiency, and reliability. Supporting Dual Channel Non-ECC Unbuffered DDR5 memory, it accommodates up to 64GB of RAM with speeds up to 3200MHz, ensuring exceptional multitasking and faster system responsiveness.

Equipped with a PCIe 3.0 x4 M.2 slot, the motherboard enables ultra-fast NVMe SSD storage for reduced loading times and enhanced overall performance. It also features a Realtek GbE LAN chip offering up to 1Gbps network speed with bandwidth management support for stable and optimized connectivity. For visuals, the HDMI 2.1 port delivers high-definition display output, making it perfect for gaming, multimedia, and creative workflows.

The GIGABYTE H610M K DDR5 ensures high-quality audio with premium capacitors and an integrated audio noise guard, providing a clean and immersive sound experience. Smart Fan 6 technology helps maintain system efficiency by utilizing multiple temperature sensors and hybrid fan headers with fan stop functionality for intelligent cooling control. The motherboard’s Anti-Sulfur resistor design enhances component durability and long-term reliability, even under demanding conditions.

Featuring the GIGABYTE APP Center, users can easily manage and customize system settings through an intuitive interface, optimizing both performance and usability. Compact yet powerful, the GIGABYTE H610M K DDR5 Micro ATX Motherboard combines cutting-edge features with dependable build quality, making it an excellent foundation for any high-performance PC build.

Buy the GIGABYTE H610M K DDR5 Micro ATX Motherboard from Tech Buy BD for authentic products and the best deals in Bangladesh.
