GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard

GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard

Brand: Gigabyte (Intel)
SKU: B760M DS3H WIFI6E GEN5
Availability: Out Of Stock

Key Features

Graphics Output: 2x DisplayPort, 1x HDMI
Features: Realtek 2.5GbE LAN, Intel Wi-Fi 6E AX210, Bluetooth 5.3
Supported RAM: 4 x DDR5 DIMM, Max. 7600(O.C), Up to 256 GB
Supported CPU: 14th 13th Gen & 12th Gen Processors (LGA1700)

Ask an expert
Tk 19,500
Tk 20,000
Tk 19,500
Subtotal: Tk 19,500
Description

Specification

Basic Information

Supported CPU LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors
L3 cache varies with CPU
Chipset Intel B760 Express Chipset
BIOS 1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
Audio Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out

Expansion Slots

PCI CPU: 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16
Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
M.2 Socket CPU: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe



Memory

Type DDR5
Slots 4 x DIMM sockets
Supported Memory 14th and 13th Generation Intel Core i9/i7 Processors:
Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.)/ 5600/5200/4800/4400 MT/s memory modules
13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:
Support for DDR5 4800/4400 MT/s memory modules
4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Maximum Memory up to 256 GB (64 GB single DIMM capacity) of system memory



Graphics

Graphics Integrated Graphics Processor-Intel HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Support for HDMI 2.1 version and HDCP 2.3.
Support for native HDMI 2.1 TMDS compatible ports.
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
Support for DisplayPort 1.2 version and HDCP 2.3
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
Support for DisplayPort 1.2 version.
(Graphics specifications may vary depending on CPU support.)
Support for up to triple-display at the same time



Connector & Ports

HDMI 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Display Port (s) 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
USB (s) Chipset: 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)
2 x USB 2.0/1.1 ports on the back panel
Chipset+USB 2.0 Hub: 4 x USB 2.0/1.1 ports available through the internal USB headers
LAN Port (s) Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless Communication module Intel Wi-Fi 6E AX210
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
BLUETOOTH 5.3
Support for 11ax 160MHz wireless standard
(Actual data rate may vary depending on environment and equipment.)
Supported Storage CPU:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
- 4 x SATA 6Gb/s connectors
RAID RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Audio 1 x front panel audio header
3 x audio jacks
Internal I/O Ports Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
2 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x S/PDIF Out header
1 x Q-Flash Plus button
1 x reset jumper
1 x Clear CMOS jumper
Back Panel Connectors
2 x USB 2.0/1.1 ports
1 x PS/2 keyboard/mouse port
2 x antenna connectors (2T2R)
1 x HDMI port (Note)
2 x DisplayPorts (Note)
3 x USB 3.2 Gen 1 ports
1 x USB Type-C® port, with USB 3.2 Gen 2 support
1 x RJ-45 port
3 x audio jacks



Others

Special Features Support for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup
Bundled Software Norton® Internet Security (OEM version)

Warranty

Warranty 3 years

Description

GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard

The GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard is designed for users who demand modern performance, connectivity, and reliability in a compact form factor. Built on the Intel B760 Express chipset, it supports 14th, 13th, and 12th Generation Intel Core, Pentium Gold, and Celeron processors through the LGA1700 socket, ensuring compatibility with the latest computing technologies. This motherboard provides a powerful foundation for gaming, content creation, and productivity systems, delivering both speed and stability.

With four DDR5 DIMM slots supporting up to 256GB of dual-channel memory, it enables ultra-fast performance with speeds of up to 7600MHz when overclocked. It supports both ECC and non-ECC memory modules and Intel XMP profiles for seamless memory tuning. For high-end graphics and multi-monitor setups, the motherboard offers HDMI 2.1 and multiple DisplayPort outputs, supporting up to 4K resolution at 60Hz. The Realtek audio codec provides 7.1-channel HD sound with S/PDIF output, ensuring clear and immersive audio quality.

Storage flexibility is enhanced with two PCIe 4.0 x4 M.2 slots for high-speed NVMe SSDs and four SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support, enabling both speed and redundancy. Expansion options include a PCIe 5.0 x16 slot for next-generation GPUs and two PCIe 3.0 x1 slots for additional devices. Networking is a highlight, featuring Realtek 2.5GbE LAN and Intel Wi-Fi 6E AX210, which offers ultra-fast wireless connectivity across 2.4GHz, 5GHz, and 6GHz bands, along with Bluetooth 5.3 support for modern peripherals.

The GIGABYTE B760M DS3H WIFI6E GEN5 also features Smart Fan 6 technology for efficient cooling, multiple RGB and ARGB headers for customization, and Q-Flash Plus for BIOS updates without CPU or memory installation. Its rear I/O includes USB 3.2 Gen2 Type-C, USB 3.2 Gen1, USB 2.0, HDMI, DisplayPort, RJ-45 LAN, and audio ports, as well as Wi-Fi antenna connectors for maximum convenience.

Compact yet powerful, the GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard combines next-generation performance, reliable connectivity, and extensive expandability to meet the needs of modern PC builders. Whether for gaming, creative work, or everyday computing, it delivers exceptional versatility and long-term reliability.

Buy the GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard from Tech Buy BD for authentic products and the best prices in Bangladesh.
