ASUS PRIME Z890M-PLUS WIFI-CSM LGA 1851 mATX Motherboard
ASUS PRIME Z890M-PLUS WIFI-CSM LGA 1851 mATX Motherboard
ASUS PRIME Z890M-PLUS WIFI-CSM LGA 1851 mATX Motherboard
ASUS PRIME Z890M-PLUS WIFI-CSM LGA 1851 mATX Motherboard
ASUS PRIME Z890M-PLUS WIFI-CSM LGA 1851 mATX Motherboard

ASUS PRIME Z890M-PLUS WIFI-CSM LGA 1851 mATX Motherboard

Brand: ASUS
SKU: TUF-Z890-PRO-WIFI
Availability: In stock

Key Features

  • Model: PRIME Z890M-PLUS WIFI-CSM
  • Supported CPU: Intel Core Ultra Processors (Series 2), LGA 1851
  • Supported RAM: 4x DDR5, Max 192GB,Supports up to 8666+MT/s (OC)
  • Graphics Output: 1x HDMI, 1x DisplayPort, 1 x USB 20Gbps port (USB Type-C)
  • Features: 3x M.2, Intel Wi-Fi 7, Bluetooth 5.4
Ask an expert
Tk 37,300
Tk 41,010
Tk 37,300
Subtotal: Tk 37,300
Description

Specification

Basic Information

Supported CPU Intel Core Ultra Processors(Series 2), LGA1851

Support Intel Core Ultra Processors (Series 2) , LGA1851
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset Intel Z890 Chipset
BIOS 256 (128+128) Mb Flash ROM, UEFI AMI BIOS
Form Factor mATX Form Factor
9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Expansion Slots

PCI Intel Core Ultra Processors (Series 2)*
1 x PCIe 5.0 x16 slot
Intel Z890 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
2 x PCIe 4.0 x16 slots (support x1 mode)
M.2 Socket Total supports 3 x M.2 slots and 6 x SATA 6Gb/s ports*
Intel Core Ultra Processors (Series 2)*
M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
Intel Z890 Chipset
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
6 x SATA 6Gb/s ports



Memory

Type DDR5
Slots 4 x DIMM slots
Supported Memory Support up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel® Extreme Memory Profile (XMP)
ASUS Enhanced Memory Profile III(AEMPIII)
Maximum Memory 192GB



Graphics

Graphics 1 x DisplayPort
1 x HDMI port
1 x USB 20Gbps port (USB Type-C) supports DisplayPort video output
*Graphics specifications may vary between CPU types



Connector & Ports

HDMI 1 x HDMI
Display Port (s) 1 x DisplayPort
1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output
USB (s) Rear USB (Total 8 ports)
1 x USB 20Gbps port (1 x USB Type-C with DP Alt mode)
1x USB 10Gbps port (1 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A) **
Front USB (Total 7 ports)
1 x USB 5Gbps connector (supports USB Type-C)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports**
* USB Type-C power delivery output: max. 5V/3A
** USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.
LAN Port (s) 1 x Intel 2.5Gb Ethernet
TUF LANGuard
Wireless Communication module Wi-Fi 7*
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
Bluetooth® v5.4***
*Wi-Fi features may vary depending on the operating system
For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
For Windows 10, please note that no driver is available , please refer to the Wi-Fi chipset vendor's website for details.
** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.
*** The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
Supported Storage 3 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
RAID Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5.
Audio 3 x Audio jacks
Internal I/O Ports Fan and cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V CPU Power connector
1 x 4-pin +12V CPU Power connector
Storage related
3 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
USB
1 x USB 5Gbps connector (supports USB Type-C)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x S/PDIF Out header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin Front System Panel header
1 x Thunderbolt (USB4) header

Back Panel I/O Ports
1 x USB 20Gbps port (1 x USB Type-C with DP Alt mode)
1x USB 10Gbps port (1 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x HDMI port
1 x Wi-Fi module
1 x Realtek 2.5Gb Ethernet
3 x Audio jacks
1 x BIOS FlashBack button
TPM (Trusted Platform Module ) 1 x SPI TPM header (14-1pin)



Others

Special Features ASUS 5X PROTECTION III
- DIGI+ VRM (- Digital power design with DrMOS)
- LANGuard
- Overvoltage Protection
- SafeSlot
- Stainless-Steel Back I/O
ASUS Q-Design
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED Core
- Q-Slot
ASUS Thermal Solution
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- ProCool
- Pre-mounted I/O shield
Aura Sync
- Aura RGB header
- Addressable Gen 2 headers
Bundled Software ASUS Exclusive Software
Armoury Crate
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
ASUS AI Advisor
ASUS DriverHub
ASUS GlideX
TurboV Core
ASUS CPU-Z
Norton 360 for Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey

Warranty

Warranty 3 years

Description

ASUS TUF GAMING Z890-PRO WIFI LGA1851 ATX Motherboard

The ASUS TUF GAMING Z890-PRO WIFI LGA1851 ATX Motherboard is a powerhouse built for elite gamers, creators, and professionals who demand next-level performance and stability. Designed around the Intel Z890 chipset and LGA1851 socket, it supports the latest Intel Core Ultra Series processors, combining exceptional power delivery, advanced cooling, and military-grade durability in a full-sized ATX form factor.

With support for up to 192GB of DDR5 memory running at overclocked speeds of 8400+MT/s, this motherboard ensures lightning-fast performance for gaming, rendering, and AI-driven workloads. The robust 10+1+2+1 power stage architecture ensures stable power delivery even under extreme load, making it perfect for overclocking and long-term reliability.

The ASUS TUF GAMING Z890-PRO WIFI offers comprehensive expansion options, including multiple PCIe 5.0 slots for next-generation GPUs and high-speed devices. For storage, it features three M.2 slots (PCIe 5.0 and 4.0 support) and six SATA 6Gb/s ports, giving users incredible flexibility for both speed and capacity.

Connectivity is top-tier, powered by Wi-Fi 7 for ultra-fast wireless networking, Realtek 2.5Gb Ethernet for rock-solid wired connections, and Bluetooth 5.4 for seamless peripheral pairing. It also features a USB 20Gbps Type-C port with DisplayPort Alt Mode and USB PD 3.0 fast charging up to 30W, ensuring modern devices and accessories perform at their best.

ASUS integrates advanced AI technologies to make performance tuning effortless. AI Overclocking automatically analyzes the CPU and cooling capabilities to achieve optimal performance, while AI Cooling II adjusts fan speeds dynamically to maintain silent and efficient operation. AI Networking II prioritizes bandwidth intelligently, optimizing connectivity for gaming, streaming, and productivity.

Thermal management is handled through comprehensive VRM, chipset, and M.2 heatsinks, keeping temperatures low during intense use. Reinforced PCIe SafeSlot designs, TUF capacitors, and ESD Guards ensure the motherboard can endure heavy gaming sessions and long-term operation with unmatched reliability.

Aesthetically, the board features ASUS Aura Sync RGB lighting for customizable illumination across your build. Its black-and-gray industrial design embodies TUF’s signature rugged style, appealing to gamers who value both durability and visual appeal.

With AI-enhanced features, premium connectivity, and military-grade components, the ASUS TUF GAMING Z890-PRO WIFI is built to dominate modern gaming and creative workloads while offering future-ready performance and rock-solid stability.

Price in Bangladesh: 37,300৳
Buy the ASUS TUF GAMING Z890-PRO WIFI LGA1851 ATX Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This product includes a 3-year warranty.
