Brand: ASUS
SKU: TUF-Z890-PRO-WIFI
Availability: In stock

Key Features

Model: TUF GAMING Z890-PRO WIFI

Supported CPU: Intel Core Ultra Processors (Series 2), LGA 1851

Supported RAM: 4x DDR5, Max 192GB,Supports Up to 9066+MT/s (OC)

Graphics Output: 1x HDMI, 1x DisplayPort, 2x Intel Thunderbolt 4 ports (USB Type-C)

Features: 4x M.2, Intel Wi-Fi 7, Bluetooth 5.4

Ask an expert
Tk 52,300
Tk 57,290
Tk 52,300
Subtotal: Tk 52,300
Description

Specification

Basic Information

Supported CPU Intel Core Ultra Processors(Series 2), LGA1851

Support Intel Core Ultra Processors (Series 2) , LGA1851
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset Intel Z890 Chipset
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Form Factor ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Audio Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz playback*
Audio Features
- Audio Shielding
- Rear optical S/PDIF out port
- Premium audio capacitors
- Dedicated audio PCB layers
- Audio cover
- Unique de-pop circuit
* Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.

Expansion Slots

PCI Intel Core Ultra Processors(Series 2)*
1 x PCIe 5.0 x16 slot
Intel Z890 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
1 x PCIe 4.0 x4 slot
2 x PCIe 4.0 x1 slots
M.2 Socket Total Supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel Core Ultra Processors(Series 2)*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
Intel Z890 Chipset
M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
4 x SATA 6Gb/s ports



Memory

Type DDR5
Slots 4 x DIMM slots
Supported Memory Support up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel Extreme Memory Profile (XMP) memory module
ASUS Enhanced Memory Profile III(AEMPIII)
Maximum Memory 192GB



Graphics

Graphics 1 x DisplayPort
1 x HDMI port
2 x Intel Thunderbolt 4 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs
* Graphics specifications may vary between CPU types



Connector & Ports

HDMI 1 x HDMI
Display Port (s) 1 x DisplayPort
2 x Intel Thunderbolt 4 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs
USB (s) Rear USB (Total 8 ports)
2 x Thunderbolt 4 ports (2 x USB Type-C)
6 x USB 10Gbps ports (6 x Type-A)
Front USB (Total 7 ports)
1 x USB 20Gbps (supports USB Type-C with up to 30W PD/PPS Fast-charge )*
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
* USB Type-C power delivery output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A
LAN Port (s) 1 x Intel 2.5Gb Ethernet
TUF LANGuard
Wireless Communication module Wi-Fi 7*
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
Bluetooth v5.4***
*Wi-Fi features may vary depending on the operating system
For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
For Windows 10, please note that no driver is available , please refer to the Wi-Fi chipset vendor's website for details.
** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.
*** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
Supported Storage 4 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
RAID Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only support RAID 0/1/5.
Audio 5 x Audio jacks
Internal I/O Ports Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connectors
Storage Related
4 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 20Gbps connector (supports USB Type-C)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x 10-1 pin Front System Panel header
1 x Thermal Sensor header
1 x Thunderbolt (USB4) header

Back Panel I/O Ports
2 x Thunderbolt 4 USB Type-C ports
6 x USB 10Gbps ports (6 x Type-A)
1 x DisplayPort
1 x HDMI port
1 x Wi-Fi module
1 x Intel 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack button



Others

Special Features ASUS TUF PROTECTION
- DIGI+ VRM (- Digital power design with DrMOS)
- ESD Guards
- TUF LANGuard
- Overvoltage protection
- SafeSlot
- Stainless-steel back I/O
ASUS Q-Design
- M.2 Q-Latch
- M.2 Q-Release
- M.2 Q-Slide
- Q-Release Slim (with PCIe SafeSlot)
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- CPU Socket lever protector
- ProCool
- Pre-mounted I/O shield
- SafeDIMM
Aura Sync
- Addressable Gen 2 headers
Front Panel USB 20Gbps with PD Fast Charge Support
- Support: up to 30W fast charging and USB Wattage Watcher
- Output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A
- Compatible with PD3.0
Bundled Software ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
ASUS DriverHub
ASUS GlideX
USB Wattage Watcher
TurboV Core
TUF GAMING CPU-Z
DTS Audio Processing
Adobe Creative Cloud (Free Trial)
Norton 360 for Gamers (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey
NPU Boost

Warranty

Warranty 3 years

Description

ASUS TUF GAMING Z890-PRO WIFI LGA1851 ATX Gaming Motherboard

The ASUS TUF GAMING Z890-PRO WIFI LGA1851 ATX Gaming Motherboard is a premium, performance-driven solution built for gamers, creators, and professionals who demand durability, speed, and stability. Powered by the advanced Intel® Z890 chipset, this motherboard supports the latest Intel® Core™ Ultra Series processors through the LGA1851 socket, delivering exceptional multitasking and processing power for gaming, rendering, and AI workloads.

Engineered with military-grade components and ASUS’s renowned reliability, the TUF GAMING Z890-PRO WIFI ensures consistent performance under intense workloads. Its four DDR5 DIMM slots support up to 192GB of memory, with overclocked speeds reaching 9066+MT/s, allowing for ultra-fast data access and smooth multitasking. Combined with Intel XMP and ASUS Enhanced Memory Profile III (AEMP III), this motherboard guarantees optimal memory stability and performance tuning.

For next-generation expandability, the TUF GAMING Z890-PRO features multiple PCIe 5.0 slots, providing blazing-fast data transfer speeds and future-ready support for the latest GPUs and high-performance storage devices. With four M.2 slots (including PCIe 5.0 support) and four SATA 6Gb/s ports, it offers unmatched flexibility for storage configurations, from rapid NVMe drives to large-capacity HDDs.

Connectivity is one of this motherboard’s strongest points, featuring WiFi 7 for ultra-low latency wireless networking and 2.5Gb Ethernet for stable, high-speed wired connections. The inclusion of Bluetooth 5.4 ensures seamless connectivity for peripherals and accessories. Additionally, the comprehensive USB setup includes USB 20Gbps Type-C® with DisplayPort Alt Mode and USB PD 3.0 fast charging up to 30W, offering exceptional compatibility and convenience for modern devices.

The ASUS TUF GAMING Z890-PRO WIFI excels in thermal efficiency and power delivery. With a 16+1+2+1 power stage design, it ensures consistent and efficient power delivery to the CPU and GPU, even under heavy loads. The advanced cooling system includes enlarged VRM heatsinks, M.2 heatsinks, multiple fan headers, and AI Cooling II technology, which intelligently manages fan speeds for optimal thermal performance while maintaining quiet operation.

For enthusiasts and professionals, the motherboard also integrates intelligent AI features such as AI Overclocking, AI Cooling II, and AI Networking II. These technologies automatically fine-tune performance, cooling, and network settings for the best balance between power, efficiency, and stability — delivering a true next-gen computing experience.

Aesthetically, the board’s rugged design is complemented by customizable Aura Sync RGB lighting, allowing full control and synchronization across compatible components. The Q-Design features like M.2 Q-Latch, PCIe Slot Q-Release, and a pre-mounted I/O shield make installation effortless, making it ideal for both beginners and experienced builders.

With its combination of top-tier components, intelligent performance tuning, and cutting-edge connectivity, the ASUS TUF GAMING Z890-PRO WIFI LGA1851 ATX Gaming Motherboard is a perfect choice for high-end gaming rigs and professional workstations.

Price in Bangladesh: 52,300৳
Buy the ASUS TUF GAMING Z890-PRO WIFI LGA1851 ATX Gaming Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This product comes with a 3-year warranty.
