Brand: ASUS
SKU: B760M-F-WIFI
Availability: In stock

Key Features

  • Model: PRIME B760M-F WIFI
  • Supported CPU: 14th, 13th Gen & 12th Gen Processors (LGA1700)
  • Supported Memory: 2 x DIMM, Max. 96GB, DDR5
  • Graphics Output: 1 x HDMI, 1 x DP, 3 x Audio
  • Features: 1 x Realtek 1Gb Ethernet, WIFI 6
Ask an expert
Tk 17,500
Tk 18,800
Tk 17,500
Subtotal: Tk 17,500
Description

Specification

Basic Information

Supported CPU Intel Socket LGA1700 for Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold and Celeron Processors
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset Intel B760 Chipset
BIOS 128 Mb Flash ROM, UEFI AMI BIOS
Form Factor micro-ATX Form Factor
9.6 inch x 8.3 inch (24.4cm x 21.1cm)
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers

Expansion Slots

PCI Intel Core Processors (14th & 13th & 12th Gen)
1 x PCIe 4.0 x16 slot
Intel B760 Chipset
1 x PCIe 4.0 x1 slot
M.2 Socket Total supports 2 x M.2 slots



Memory

Type DDR5
Slots 2 x DIMM
Supported Memory 8000(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory*
Dual channel memory architecture
Supports Intel® Extreme Memory Profile (XMP) memory module
Maximum Memory Max. 96GB



Graphics

Graphics ** Supports 4K@30Hz as specified in HDMI 1.4.



Connector & Ports

HDMI 1x HDMI port
Display Port (s) 1x DisplayPort
USB (s) Rear USB (Total 6 ports)
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 5 ports)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 3 additional USB 2.0 ports
LAN Port (s) 1 x Realtek 1Gb Ethernet port
Wireless Communication module Wi-Fi 6
Supported Storage Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel Core Processors (14th & 13th & 12th Gen)
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
Intel B760 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
4 x SATA 6Gb/s ports
RAID Intel Rapid Storage Technology supports SATA RAID 0/1/5/10.
Audio 3 x Audio jacks
Internal I/O Ports Internal I/O Connectors
Fan and Cooling Related
1 x 4-pin CPU Fan header
2 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage Related
2 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 3 additional USB 2.0 ports
Miscellaneous
2 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x COM Port header
1 x Front panel audio header (F_AUDIO)
1 x S/PDIF Out header
1 x Speaker header
1 x 10-1 pin System Panel header


Back Panel I/O Ports
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x HDMI port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
TPM (Trusted Platform Module ) 1 x SPI TPM header (14-1pin)



Others

Special Features ASUS 5X PROTECTION III
- DIGI+ VRM
- LANGuard
- Overvoltage protection
- SafeSlot Core
- Stainless-steel back I/O
ASUS Q-Design
- Q-DIMM
- Q-LED Core
- Q-Slot
ASUS EZ DIY
- ProCool
ASUS Thermal Solution
- Aluminum heatsink design
Aura Sync
- Addressable Gen 2 headers
Bundled Software ASUS Exclusive Software
Armoury Crate
- Aura Sync
- Fan Xpert 2+
- Power Saving
- Two-Way AI Noise Cancelation
AI Suite 3
- DIGI+ VRM
- PC Cleaner
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode

Warranty

Warranty 3 years

Description

Asus PRIME B760M-F WIFI mATX Motherboard

The Asus PRIME B760M-F WIFI mATX Motherboard is a feature-packed and compact motherboard designed for users who want high performance, advanced connectivity, and reliable power efficiency in a small form factor. Powered by the Intel B760 chipset, it supports Intel 12th, 13th, and 14th Gen Core processors, including Pentium Gold and Celeron CPUs, through the LGA1700 socket—making it ideal for gaming, productivity, and content creation.

With dual DDR5 DIMM slots supporting up to 96GB of memory and speeds up to 8000MHz (OC), this motherboard delivers exceptional performance for multitasking and demanding workloads. Storage expansion is optimized with dual PCIe 4.0 x4 M.2 slots for ultra-fast NVMe SSDs and four SATA 6Gb/s ports for additional storage devices. For graphics and expansion, the board includes one PCIe 5.0 x16 slot and one PCIe 4.0 x1 slot, offering flexibility for high-end GPUs and other add-on cards.

Networking and wireless capabilities are cutting-edge, featuring integrated Wi-Fi 6, Realtek 1Gb Ethernet, and Bluetooth 5.3 for stable and high-speed connectivity. The rear I/O provides a variety of USB options, including four USB 3.2 Gen 1 (5Gbps) ports, two USB 2.0 ports, and headers for additional front-panel connectivity. HDMI and DisplayPort outputs support 4K resolution, while Realtek high-definition audio delivers rich, immersive sound for entertainment and gaming.

Cooling and power management are efficiently handled through ASUS Fan Xpert 2+, DIGI+ VRM, and an 8-pin ProCool power connector, ensuring consistent performance and thermal stability. Aura Sync RGB lighting support, with two Addressable Gen 2 headers, lets users customize their system’s appearance with synchronized lighting effects across compatible components.

With AI noise cancellation, intuitive UEFI BIOS, and solid build quality, the Asus PRIME B760M-F WIFI mATX Motherboard strikes the perfect balance between performance, stability, and customization—making it an excellent foundation for modern compact desktop builds.

Price in Bangladesh: 17,500৳
Buy the Asus PRIME B760M-F WIFI mATX Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This product includes a 3-year warranty.
