Asus PRIME A620M-K AM5 mATX Motherboard
Asus PRIME A620M-K AM5 mATX Motherboard

Asus PRIME A620M-K AM5 mATX Motherboard

Brand: ASUS
SKU: PRIME-A620M-K
Availability: In stock

Key Features

Model: PRIME A620M-K

Supported CPU: Ryzen 9000/8000/ 7000 Series Processors for Socket AM5

Supported RAM: 2x DDR5, up to 96GB, 7200+(OC)

Graphics Output: 1x HDMI, 1 x VGA

Features: 1 x Realtek 1Gb Etherne

Ask an expert
Tk 11,700
Tk 12,870
Tk 11,700
Subtotal: Tk 11,700
Description

Specification

Basic Information

Supported CPU AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
Chipset AMD A620 Chipset
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Form Factor micro-ATX Form Factor
8.9 inch x 8.7 inch (22.6 cm x 22.1 cm)
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers

Expansion Slots

PCI AMD Ryzen 9000 & 7000 Series Desktop Processors*
1 x PCIe 4.0 x16 slot (supports x16 mode)
AMD Ryzen 8000 Series Desktop Processors
1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**
AMD A620 Chipset
1 x PCIe 3.0 x1 slot



Memory

Type DDR5
Slots 2 x DIMM slots
Supported Memory 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports AMD Extended Profiles for Overclocking (EXPO)
Maximum Memory Max. 96GB



Graphics

Graphics 1 x VGA port
1 x HDMI port



Connector & Ports

HDMI 1x HDMI
VGA (s) 1 x VGA port
USB (s) Rear USB (Total 6 ports)
4 x USB 3.2 Gen 1 (5G) ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 6 ports)
1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
LAN Port (s) 1 x Realtek 1Gb Ethernet
Supported Storage Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports*
AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
AMD A620 Chipset
4 x SATA 6Gb/s ports
* AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/10 and SATA RAID 0/1/10.
Audio 3 x Audio jacks
Internal I/O Ports Internal I/O Connectors

Fan and Cooling-related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
1 x M.2 slot (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
2 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x Speaker header
1 x 10-1 pin System Panel header

Back Panel I/O Ports

4 x USB 3.2 Gen 1 (5G) ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x VGA port
1 x HDMI port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port
TPM (Trusted Platform Module ) 1 x SPI TPM header (14-1pin)



Others

Special Features ASUS 5X PROTECTION III
- DIGI+ VRM
- LANGuard
- Overvoltage Protection
- SafeSlot Core
- Stainless-Steel Back I/O
ASUS Q-Design
- Q-DIMM
- Q-LED Core
- Q-Slot
ASUS Thermal Solution
- Aluminum heatsink design
Aura Sync
- Aura RGB header
- Addressable Gen 2 headers
Bundled Software ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert
- Power Saving
- Two-Way AI Noise Cancellation
AI Suite 3
- TurboV EVO
- DIGI+ VRM
- PC Cleaner
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode



Warranty

Warranty 3 years

Description

Asus PRIME A620M-K AM5 mATX Motherboard

The Asus PRIME A620M-K AM5 mATX Motherboard is built to deliver stable performance, advanced connectivity, and efficient cooling for modern desktop setups powered by the latest AMD Ryzen processors. Designed with the AM5 socket and AMD A620 chipset, this motherboard ensures compatibility with next-generation Ryzen CPUs, offering users a solid foundation for productivity, gaming, or AI-based workloads.

With support for PCIe 4.0, the Asus PRIME A620M-K enables lightning-fast data transfer between the CPU, graphics card, and storage devices, providing the speed required for intensive applications. It includes a 64Gbps M.2 slot for high-speed NVMe SSDs and four SATA 6Gb/s ports for additional storage, giving users flexible options for both performance and capacity. Networking reliability is guaranteed through the Realtek 1Gb Ethernet, ensuring smooth and stable connectivity for online gaming, streaming, or professional use.

Connectivity options include multiple USB 3.2 Gen 1 Type-A ports, providing fast data transfer for peripherals such as external drives and accessories. To maintain optimal system performance, the motherboard incorporates comprehensive cooling features, including a PCH heatsink and ASUS Fan Xpert technology, which intelligently adjusts fan speeds to balance temperature and noise.

Aesthetic customization is enhanced with Aura Sync RGB lighting, featuring both Addressable Gen 2 headers and an Aura RGB header. This allows users to connect and synchronize lighting effects across compatible components for a unified and visually dynamic PC build. Additionally, the two-way AI noise cancelation technology reduces unwanted background noise from both the microphone and audio output, ensuring clear and uninterrupted communication during gaming sessions or video calls.

The Asus PRIME A620M-K AM5 Motherboard is also backed by ASUS 5X Protection III, which includes safeguards like overvoltage protection, safe slot reinforcement, and ESD guards for enhanced hardware reliability. Its intuitive UEFI BIOS makes system configuration simple, catering to both beginners and advanced users.

Compact yet powerful, the Asus PRIME A620M-K AM5 mATX Motherboard is an excellent choice for users seeking an affordable, efficient, and durable AM5 platform that blends stability, speed, and smart design.

Price in Bangladesh: 11,700৳
Buy the Asus PRIME A620M-K AM5 mATX Motherboard from Tech Buy. Order online or visit your nearest showroom to get yours at the best price. This product comes with a 3-year warranty.
